RO4200-1 RO4210-2 Niobium Capillary Tube Throttling And Pressure Increase
| Tempat asal | CINA |
|---|---|
| Nama merek | Changsheng |
| Sertifikasi | ISO 9001;2015 |
| Nomor model | ASTM B394-98 |
| Kuantitas min Order | 100 pcs |
| Harga | USD58.00/pc |
| Kemasan rincian | Paket ekspor standar |
| Waktu pengiriman | 15-30 hari |
| Syarat-syarat pembayaran | L/C, T/T, Western Union, Moneygram, Paypal |
| Menyediakan kemampuan | 500 kg/bulan |
Hubungi saya untuk sampel gratis dan kupon.
ada apa:0086 18588475571
Wechat wechat: 0086 18588475571
Skype: sales10@aixton.com
Jika Anda memiliki masalah, kami menyediakan bantuan online 24 jam.
xDetail produk
| Komoditi | tabung niobium | Komposisi Kimia | Catatan>=99,95% |
|---|---|---|---|
| Metode | Tungku Berkas Elektron Dilebur | Ukuran | ￠3~￠120mm |
| Ukuran | Disesuaikan | Kemurnian | 99,9%(3n) |
| Standar | ASTM B393 | Kondisi | Vakum Anil |
| Standar Bahan | ASTM B 365-98 | Teknik | Sintering, Penempaan, Pemesinan |
| Teknologi | Mesin Penggilingan CNC | Panas fusi | 26,4KJ/mol |
| Suhu Penguapan | 2350℃ (di bawah 10-4Torr) | Kekuatan luluh | 73MPa |
| Tahun penemuan | 1801 | Tempat asli | CINA |
| Kapasitas panas spesifik | 0,265 J/g·K | Nilai | RO4200 |
| Nomor atom | 41 | Kondisi permukaan | dibersihkan atau hitam |
| Pengolahan | Rolling dingin | Standar manufaktur | ASTM B392-95 |
| Titik lebur | 2.468 ° C. | Spesifikasi | Disesuaikan |
| Membentuk | Tabung | Konduktivitas Listrik | 0,0693 10^6/cm |
| Kepadatan | 8.57 g/cm³ | Kata kunci | tabung kapiler niobium |
Deskripsi Produk
Introduction
Niobium tube is a kind of pipe used for conveying and transferring materials under special conditions, such as high temperature and high pressure, which is widely used in the nuclear industry, aerospace, shipbuilding, chemical industry, and electronics. Due to niobium's excellent corrosion resistance and high temperature stability, niobium tubes have strong compressive, tensile, fatigue, and heat resistance characteristics, so they are widely used in various high-end fields.
Chemical Composition:
| Chemical(%) | ||||||||||||
| Grade | Main component | Other impurities(≤) | ||||||||||
| Nb | Fe | Si | Ni | W | Mo | Ti | Ta | O | C | H | N | |
| Nb1 | Remainder | 0.004 | 0.004 | 0.002 | 0.005 | 0.005 | 0.002 | 0.05 | 0.015 | 0.004 | 0.0015 | 0.003 |
| Nb2 | Remainder | 0.01 | 0.01 | 0.005 | 0.02 | 0.01 | 0.004 | 0.07 | 0.02 | 0.01 | 0.0015 | 0.008 |
Surface treatment
The surface treatment of niobium tube usually includes mechanical polishing, electrolytic polishing, pickling and sandblasting. Mechanical polishing and electrolytic polishing can improve the surface finish and flatness of the niobium tube, and improve the corrosion resistance of the niobium tube. Pickling and sand blasting can remove impurities such as oil and oxide on the surface of the niobium tube to ensure the cleanliness and flatness of the surface of the niobium tube.
Application of niobium
1, high-temperature alloy;
2, niobium base alloy;
3, steel applications;
4. Electric porcelain;
5. Money;
6. Medical field;
7. Medical field;
8. Aerospace industry
Product photo
